Camara Ip Hikvision 2cd2043g2-i / 4mp 2.8mm Acusense

Cámara

Sensor De Imagen: 1/3" Progressive Scan CMOS

Max. Resolución: 2688 × 1520

Iluminación Mínima: Color: 0.005 Lux @ (F1.6, AGC ON), 0 Lux with IR on

Tiempo De Obturación: 1/3 s to 1/100,000 s

Día Y Noche: IR cut filter

Ajuste De Ángulo: Pan: 0° to 360°,tilt: 0° to 90°,rotate: 0° to 360°

Lente

Lente: Fixed focal lens 2.8 mm

Focal Length & FOV: horizontal FOV 103°, vertical FOV 55°, diagonal FOV 122°

Montura Del Lente: M12

Iris Type: Fixed

Apertura: F1.6

DORI

DORI: D: 67 m, O: 26 m, R: 13 m, I: 6 m

Iluminador

Tipo De Luz Suplementaria: IR

Rango De Luz Suplementaria: Up to 40 m

Luz De Suplemento Inteligente: Yes

IR Wavelength: 850 nm

Vídeo

Main Stream:

- 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)

- 60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)

Sub-Stream:

- 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)

- 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)

Third Stream:

- 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)

- 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)

Compresión De Video:

- Main stream: H.265/H.264/H.264+/H.265+

- Sub-stream: H.265/H.264/MJPEG

- Third stream: H.265/H.264

Vídeo Bitrate: 32 Kbps to 8 Mbps

Tipo H.264: Baseline Profile/Main Profile/High Profile

Tipo H.265: Main Profile

Bit Rate Control: CBR/VBR

Codificación De Video Escalable (SVC): H.264 and H.265 encoding

Región De Interés (ROI): 1 fixed region for main stream and sub-stream

Red

Seguridad: Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface

Vista En Vivo Simultánea: Up to 6 channels

API: Open Network Video Interface (Profile S, Profile G), ISAPI, SDK

Protocolos: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, WebSocket, WebSockets

Usuario/Operador: Up to 32 users. 3 user levels: administrator, operator and user

Almacenamiento En Red: NAS (NFS, SMB/CIFS), auto network replenishment (ANR)

Cliente: iVMS-4200, Hik-Connect

Navegador Web:

- Plug-in required live view: IE 10, IE 11

- Local service: Chrome 57.0+, Firefox 52.0+

Imagen

Interruptor De Parámetros De Imagen: Yes

Configuración De Imagen: Rotate, mirror, privacy mask, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser

Interruptor Día/Noche: Day, Night, Auto, Schedule

Wide Dynamic Range (WDR): 120 dB

Mejora De La Imagen: BLC, HLC, 3D DNR

SNR: ≥ 52 dB

Interfaz

Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port

On-Board Storage: Built-in memory card slot, support microSD card, up to 512 GB

Reset Key: Yes

Evento

Evento Básico: Motion detection (human and vehicle targets classification), video tampering alarm, exception

Evento Inteligente: Line crossing detection, intrusion detection (support alarm triggering by specified target types (human and vehicle)) Face detection

Linkage: Upload to FTP/memory card/NAS, notify surveillance center, trigger record, trigger capture

General

Alimentación:

- 12 VDC ± 25%, 0.5 A, max. 6 W, Ø5.5 mm coaxial power plug, reverse polarity protection

- PoE: 802.3af, Class 3, 36 V to 57 V), 0.2 A to 0.13 A, max. 7 W

Material: metal

Dimensión: Ø70 × 161.7 mm (Ø2.76″ × 6.37″)

Dimensión Del Paquete: 216 mm × 121 mm × 118 mm (8.6" × 4.8" × 4.7")

Peso: Approx. 490 g (1.1 lb.)

Con Peso Del Paquete: Approx. 724 g (1.6 lb.)

Condiciones De Almacenaje: -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

Condiciones De Inicio Y Funcionamiento: -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

Idioma: 33 languages

Función General: Anti-flicker, heartbeat, password reset via e-mail, pixel counter

Certificaciones

EMC: FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015)

Seguridad: UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015)

Ambiente: CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)

Protección: IP67: IEC 60529-2013
