Camara Ip Hikvision Ds-2cd2t47g2-lsu/sl(c) 4mp Colorvu Estrobo Alarma

Cámara

Sensor De Imagen: 1/1.8" Progressive Scan CMOS

Max. Resolución: 2688 × 1520

Iluminación Mínima: Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light

Tiempo De Obturación: 1/3 s to 1/100,000 s

Día Y Noche: IR cut filter

Ajuste De Ángulo: Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°

.

Lente

Lente: Fixed focal lens 2.8 mm

Focal Length & FOV: 2.8 mm, horizontal FOV 111.9°, vertical FOV 60.5°, diagonal FOV 133.6°

Montura Del Lente: M16

Iris Type: Fixed

Apertura: F1.0

Depth Of Field: 2.8 mm: 3.1 m to ∞

.

DORI

DORI: 2.8 mm, D: 58.2 m, O: 23.1 m, R: 11.6 m, I: 5.8 m

.

Iluminador

Tipo De Luz Suplementaria: White light

Rango De Luz Suplementaria: Up to 60 m

Luz De Suplemento Inteligente: Yes

.

Vídeo

Main Stream:

- 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)

- 60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)

Sub-Stream:

- 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)

- 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)

Third Stream:

- 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)

- 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)

*Third stream is supported under certain settings.

Compresión De Video:

- Main stream: H.265/H.264/H.265+/H.264+

- Sub-stream: H.265/H.264/MJPEG

- Third stream: H.265/H.264

*Third stream is supported under certain settings.

Vídeo Bitrate: 32 Kbps to 8 Mbps

Tipo H.264: Baseline Profile,Main Profile,High Profile

Tipo H.265: Main Profile

Bit Rate Control: CBR,VBR

Codificación De Video Escalable (SVC): H.264 and H.265 encoding

Región De Interés (ROI): 1 fixed region for main stream

.

Audio

Compresión De Audio: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC

Velocidad De Bits De Audio: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)

Frecuencia De Muestreo De Audio: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz

Filtro De Ruido Ambiental: Yes

.

Red

Protocolos: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP, WebSocket, WebSockets

Vista En Vivo Simultánea: Up to 6 channels

API: Open Network Video Interface (Profile S, Profile G, Profile T),ISAPI,SDK

Usuario/Operador: Up to 32 users. 3 user levels: administrator, operator and user

Seguridad: Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.2, host authentication (MAC address)

Almacenamiento En Red:

- NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR),

- Together with high-end Hikvision memory card, memory card encryption and health detection are supported.

Cliente: iVMS-4200,Hik-Connect,Hik-Central

Navegador Web:

- Plug-in required live view: IE 10, IE 11,

- Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+,

- Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+

.

Imagen

Interruptor De Parámetros De Imagen: Yes

Configuración De Imagen: Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser

Interruptor Día/Noche: Auto, Schedule

Wide Dynamic Range (WDR): 130 dB

SNR: ≥ 52 dB

Mejora De La Imagen: BLC, HLC, 3D DNR

.

Interfaz

Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port

On-Board Storage: Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB

Micrófono Incorporado: Yes

Altavoz Incorporado: 2 W, 10 cm: 97 dB

Audio:

- 1 input (line in), two-core terminal block , max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium

- 1 output (line out),two-core terminal block , max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium

Alarma:

- Visual alarm

- 1 input, 1 output (max. 24 VDC/24 VAC, 1 A)

Reset Key: Yes

.

Evento

Evento Básico: Motion detection (human and vehicle targets classification), video tampering alarm, exception

Evento Inteligente: Line crossing detection, intrusion detection, region entrance detection, region exiting detection (support alarm triggering by specified target types (human and vehicle)) Scene change detection

Linkage: Upload to NAS/memory card/FTP, notify surveillance center, trigger recording, trigger capture, send email, strobe light, audible warning, trigger alarm output

.

Deep Learning Function

Captura De La Cara: Si

.

General

Alimentación:

- 12 VDC ± 25%, 0.67 A, max. 8 W, Ø5.5 mm coaxial power plug, reverse polarity protection

- PoE: 802.3af, Class 3, 36 V to 57 V, 0.25 A to 0.16 A, max. 9 W

Dimensión: 289.5 mm × Ø105 mm (11.4"× Ø4.1")

Dimensión Del Paquete: 386 mm × 156 mm × 155 mm (15.2" × 6.1" × 6.1")

Peso: Approx. 1165 g (2.6 lb.)

Con Peso Del Paquete: Approx. 1639 g (3.6 lb.)

Condiciones De Almacenaje: -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

Condiciones De Inicio Y Funcionamiento: -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

Función General: Anti-flicker, heartbeat, mirror, privacy mask, flash log, password reset via email, pixel counter

.

Certificaciones

EMC: FCC SDoC: 47 CFR Part 15, Subpart B; CE-EMC: EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014; RCM: AS/NZS CISPR 32: 2015; IC VoC: ICES-003: Issue 6, 2016; KC: KN 32: 2015, KN 35: 2015

Seguridad: UL: UL 60950-1; CB: IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014; CE-LVD: EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014; LOA: IEC/EN 60950-1

Ambiente: CE-RoHS: 2011/65/EU; WEEE: 2012/19/EU; Reach: Regulation (EC) No 1907/2006

Protección: IP67: IEC 60529-2013
